SERVICE MANUAL
Ver 1.0 2003.04
MICRO Hi-Fi COMPONENT SYSTEM
CMT-CPX1
CMT-CPX1
COMPACT DISC DECK
HCD-CPX1
RECEIVER
SPEAKER SYSTEM
SS-CPX1
US Model
Canadian Model
E Model
Australian Model
· CMT-CPX1 is composed of following models.
As service manuals are issued for each component model,
please refer to them.
COMPONENT MODEL NAME
ACCESSORIES
Part No.
Description
Remark
9-877-172-01
Sony Corporation
2003D0500-1
Home Audio Company
C
2003.04
Published by Sony Engineering Corporation
1-477-715-11
COMMANDER, STANDARD (RM-SMR1)
1-754-059-12
ANTENNA, LOOP (AM)
1-793-184-22
CONNECTOR (F TYPE ADAPTOR) (FM)
4-210-254-02
CUSHION (FOOT) (for SS-CPX1)
4-228-952-01
COVER, BATTERY (for RM-SMR1)
4-244-991-11
MANUAL, INSTRUCTION (ENGLISH)
4-244-991-21
MANUAL, INSTRUCTION (FRENCH) (US, Canadian)
4-244-991-31
MANUAL, INSTRUCTION (FRENCH, SPANISH)
(Singapore)
4-244-991-41
MANUAL, INSTRUCTION (TRADITIONAL CHINESE)
(Singapore)
4-244-991-51
MANUAL, INSTRUCTION (KOREAN) (Korean)
SPECIFICATIONS
Power requirements
North American model:
120 V AC, 60 Hz
Australian model:
230 ­ 240 V AC, 50/60 Hz
Other models:
220 ­ 240 V AC, 50/60 Hz
Korean model:
220 V AC, 60 Hz
Power consumption:
50 W
Dimensions (w/h/d) incl. projecting parts and controls
Amplifier/Tuner/Tape/CD section:
Approx. 174
×
××
240.5
× 291
mm
Speakers:
Approx. 160
240
240
mm
Mass
Amplifier/Tuner/Tape/CD section:
Approx. 4.3 kg
Speakers:
Approx. 3.1 kg net per
speaker
Supplied accessories
Remote (1)
R6 (size AA) batteries (2)
AM loop antenna (1)
FM lead antenna (1)
Speaker pads (8)
Design and specifications are subject to change
without notice.


background image
2
CMT-CPX1
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver.
Date
Description of Revision
1.0
2003.04
New
