KV-32FV1/34FVL1/36FV1
TRINITRON® COLOR TV
SERVICE MANUAL
CHASSIS
AA-2H
MODEL
COMMANDER
DEST.
CHASSIS NO.
KV-32FV1
RM-Y167
US
SCC-S18B-A
KV-32FV1
RM-Y167
CND
SCC-S19B-A
KV-34FVL1
RM-Y167
E
SCC-S20B-A
KV-36FV1
RM-Y167
US
SCC-S18C-A
KV-36FV1
RM-Y167
CND
SCC-S19C-A
KV-36FV1
RM-Y167


background image
-- 2 --
KV-32FV1/34FVL1/36FV1
SPECIFICATIONS
(1) 1 Vp-p, 75 ohms unbalanced, sync negative
(2) Y: 1 Vp-p, 75 ohms unbalanced, sync negative C: 0.286 Vp-p (Burst signal), 75 ohms
(3) 500 mVrms (100% modulation); Impedance: 47 kilohms
(4) More than 408 mVrms at the maximum volume setting (variable) More than 408mVrms (fix); Impedance (Output): 2 kilohms
(5) Y: 1.0 Vp-p, 75 ohms, sync negative; PB: 0.7 Vp-p, 75 ohms; PR: Vp-p, 75 ohms
** Design and specifications are subject to change without notice.
Television system
American TV standard, NTSC
Channel coverage
VHF
:
2-13
UHF
:
14-69
CATV
:
1-125
Antenna
75-ohm external antenna terminal for VHF / UHF
Picture tube
FD Trinitron® tube
Visible Screen Size
32-inch picture measured diagonally (KV-32FV1/34FVL1)
36-inch picture measured diagonally (KV-36FV1)
Actual Screen Size
34-inch picture measured diagonally (KV-32FV1/34FVL1)
38-inch picture measured diagonally (KV-36FV1)
(
q)® SRS (SOUND RETRIEVAL SYSTEM)
The (
q) SRS (SOUND RETRIEVAL SYSTEM) is
manufactured by Sony Corporation under license
from SRS Labs, Inc. It is covered by U.S. Patent No.
4,748,669. Other U.S. and foreign patents pending.
The word "SRS" and the SRS symbol (
q) are
registered trademarks of SRS Labs, Inc.
Supplied Accessories Remote control RM-Y167,
Battery size AA (R6) 2
Optional accessories
Connecting cables
RK-74A, RK-G69HG,
VMC-10HG, VMC-720M,
VMC-810S/820S, YC-15V/30V,
TV Stand SU-32FD1, SU-36FD1
U/V mixer EAC-66
KV-32FV1
KV-34FVL1
KV-36FV1
Power requirements
120V,60Hz
Number of inputs/outputs
Video 1)
3
S Video 2)
2
Audio 3)
4
Audio Out 4)
1
Monitor Out
1
TV out 1) 3)
1
S-link
3
Y, PB, PR 5)
1
Speaker output (W)
15Wx2
Power Consumption (W)
In use (max.)
240W
In standby
2W
Dimensions (W/H/D)
(mm)
889.4 X 685.6 x 600.7 mm
1010 X 761.2 X 630.9 mm
(in.)
357/16 x 27 x 2321/32 in
3913/16 x 30 x 2415/16 in
Mass
(kg.)
79 kg
107 kg
(lbs.)
175 lbs
236 lbs


background image
-- 3 --
KV-32FV1/34FVL1/36FV1
ATTENTION!!
AFIN D'EVITER TOUT RESQUE D'ELECTROCUTION PROVENANT D'UN
CHÁSSIS SOUS TENSION, UN TRANSFORMATEUR D'ISOLEMENT DOIT
ETRE UTILISÉ LORS DE TOUT DÉPANNAGE. LE CHÁSSIS DE CE
RÉCEPTEUR EST DIRECTEMENT RACCORDÉ À L'ALIMENTATION
SECTEUR.
ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
LES COMPOSANTS IDENTIFIES PAR UNE TRAME ET PAR UNE MARQUE
¡ SUR LES SCHEMAS DE PRINCIPE, LES VUES EXPLOSEES ET LES
LISTES DE PIECES SONT D'UNEIMPORTANCE CRITIQUE POUR LA
SECURITE DU FONCTIONNEMENT. NE LES REMPLACER QUE PAR
DES COMPOSANTS SONY DONT LE NUMERO DE PIECE EST INDIQUE
DANS LE PRESENT MANUEL OU DANS DES SUPPLEMENTS PUBLIES
PAR SONY. LES REGLAGES DE CIRCUIT DONT L'IMPORTANCE EST
CRITIQUE POUR LA SECURITE DU FONCTIONNEMENT SONT IDENTI-
FIES DANS LE PRESENT MANUEL. SUIVRE CES PROCEDURES LORS
DE CHAQUE REMPLACEMENT DE COMPOSANTS CRITIQUES, OU
LORSQU'UN MAUVAIS FONTIONNEMENT SUSPECTE.
TABLE OF CONTENTS
Section
Title
Page
Section
Title
Page
ATTENTION
APRES AVOIR DECONNECTE LE CAP DE L'ANODE, COURT-CIRCUITER
L'ANODE DU TUBE CATHODIQUE ET CELUI DE L'ANODE DU CAP AU
CHASSIS METALLIQUE DE L'APPAREIL, OU AU COUCHE DE CARBONE
PEINTE SUR LE TUBE CATHODIQUE OU AU BLINDAGE DU TUBE
CATHODIQUE.
CAUTION!
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND THE
ANODE CAP TO THE METAL CHASSIS, CRT SHIELD, OR CARBON
PAINTED ON THE CRT, AFTER REMOVING THE ANODE.
WARNING!!
AN ISOLATION TRANSFORMER SHOULD BE USED DURING ANY
SERVICE TO AVOID POSSIBLE SHOCK HAZARD, BECAUSE OF LIVE
CHASSIS.
THE CHASSIS OF THIS RECEIVER IS DIRECTLY CONNECTED TO
THE AC POWER LINE.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK
¡ ON
THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN THE
PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY. CIRCUIT ADJUSTMENTS
THAT ARE CRITICAL FOR SAFE OPERATION ARE IDENTIFIED
IN THIS MANUAL. FOLLOW THESE PROCEDURES WHENEVER
CRITICAL COMPONENTS ARE REPLACED OR IMPROPER
OPERATION IS SUSPECTED.
1. GENERAL
Remote Control
5
Connecting and Installing the TV
5
Cable Box Connections
5
VCR Connections
5
DBS Connections
6
DVD Player Connections
6
Additional Connections
6
Using your New TV
7
Watching the TV
7
Watching two programs at one time - PIP
7
Using Your Menus
8
Learning menu selection
8
Using the VIDEO menu
8
Using the AUDIO menu
8
Using the TIMER menu
9
Using the SET UP menu
9
Operating Video Equipment
9
VCR manufacturer code numbers
9
MDP manufacturer code numbers
10
Operating a cable box DBS receiver
10
Troubleshooting
10
2. DISASSEMBLY
2-1.
Rear Cover and Speaker Removal
11
2-2.
Chassis Assembly Removal
11
2-3.
Service Position
11
2-4.
HX Bracket Removal
11
2-5.
Extension Cable Removal
11
2-6.
Picture Tube Removal
12
3. SET-UP ADJUSTMENTS
3-1.
Beam Landing
13
3-2.
Convergence
14
3-3.
Focus
15
3-4.
Screen (G2)
15
3-5.
White Balance Adjustment
15
4. SAFETY RELATED ADJUSTMENTS
16
5. CIRCUIT ADJUSTMENTS
17
6. DIAGRAMS
6-1.
Circuit Boards Location
26
6-2.
Printed Wiring Boards and Schematic Diagrams
26
· Block Diagram
27
· A Board
31
· HX Board
35
· HF Board
36
· UX Board
38
· AX Board
43
· B Board
45
· C Board
47
· G Board
48
· P Board
51
· K Board
53
· WA Board
55
6-3.
Semiconductors
58
7. EXPLODED VIEWS
7-1.
Chassis
59
7-2.
Picture Tube
60
8. ELECTRICAL PARTS LIST
61


background image
-- 4 --
KV-32FV1/34FVL1/36FV1
SAFETY CHECK-OUT
After correcting the original service problem, perform the
following safety checks before releasing the set to the
customer:
LEAKAGE TEST
The AC leakage from any exposed metal part to earth ground
and from all exposed metal parts to any exposed metal part having
a return to chassis, must not exceed 0.5 mA (500 microampere).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or
RCA WT-540A. Follow the manufacturers' instructions to
use these instructions.
2. A battery-operated AC milliammeter. The Data Precision
245 digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of
a VOM or battery-operated AC voltmeter. The "limit"
indication is 0.75 V, so analog meters must have an accurate
low voltage scale. The Simpson's 250 and Sanwa
SH-63Trd are examples of passive VOMs that are suitable.
Nearly all battery operated digital multimeters that have a
2V AC range are suitable. (See Fig. A)
1. Check the area of your repair for unsoldered or poorly-
soldered connections. Check the entire board surface
for solder splashes and bridges.
2. Check the interboard wiring to ensure that no wires
are "pinched" or contact high-wattage resistors.
3. Check that all control knobs, shields, covers, ground
straps, and mounting hardware have been replaced.
Be absolutely certain that you have replaced all the
insulators.
4. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous
repair. Point them out to the customer and
recommend their replacement.
5. Look for parts which, though functioning, show
obvious signs of deterioration. Point them out to
the customer and recommend their replacement.
6. Check the line cords for cracks and abrasion.
Recommend the replacement of any such line cord
to the customer.
7. Check the B+ and HV to see if they are specified
values. Make sure your instruments are accurate;
be suspicious of your HV meter if sets always have
low HV.
8. Check the antenna terminals, metal trim, "metallized"
knobs, screws, and all other exposed metal parts for
AC Leakage. Check leakage as described below.
HOW TO FIND A GOOD EARTH GROUND
A cold-water pipe is guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground.
If the retaining screw is to be used as your earth-ground, verify
that it is at ground by measuring the resistance between it and a
cold-water pipe with an ohmmeter. The reading should be zero
ohms. If a cold-water pipe is not accessible, connect a 60-l00 watts
trouble light (not a neon lamp) between the hot side of the re-
ceptacle and the retaining screw. Try both slots, if necessary, to
locate the hot side of the line, the lamp should light at normal
brilliance if the screw is at ground potential. (See Fig. B)
1.5 k
0.15 µF
AC
Voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
Fig. A. Using an AC voltmeter to check AC leakage.


background image
--
5
--
KV
-32FV1/34FVL1/36FV1
SECTION 1
GENERAL
The instructions mentioned here are partial abstracts from the Operating Instruction Manual.
The page numbers shown reflect those of the Operating Instruction Manual.
4
Connecting and Installing the TV (continued)
Cable Box Connections
Some pay cable TV systems use scrambled or
encoded signals that require a cable box to
view all channels.
Cable box
1 Connect the coaxial connector from your
cable to the IN on your cable box.
2 Using a coaxial cable, connect OUT on
your cable box to VHF/UHF on your TV.
Cable box and cable
For this set up, you can switch between
scrambled channels (through your cable box),
and normal (CATV) channels by pressing
ANT on your remote control.
Notes
· Your Sony remote control can be
programmed to operate your cable box.
(see page 26)
· When using PIP, you cannot view the
AUX input in the window picture.
Tip z
PressingANTswitchesbetweentheseinputs.
TO CONVERTER
Cable box
VHF/UHF
(Rear of TV)
AUX
75-ohm coaxial
cable (not supplied)
CATV cable
(unscrambled channels)
(signal)
scrambled
channels
If you are connecting a cable box through the AUX input and
would like to switch between the AUX and normal (CATV) input
you should consider using the CHANNEL FIX feature. (see page 24)
Cable box
Cable
OUT
IN
(Rear of TV)
VHF/UHF
If you will be controlling all channel selection
through your cable box, you should consider
using the CHANNEL FIX feature. (see page 24)
5
VCR Connections
Connecting an antenna/cable TV
system with a VCR
1 Attach the coaxial connector from your
cable or antenna to IN on your VCR.
2 Using A/V connectors, connect AUDIO
and VIDEO OUT on your VCR to AUDIO
and VIDEO IN on your TV*.
3 Using a coaxial connector, connect OUT on
your VCR to VHF/UHF on your TV.
* If you are connecting a monaural VCR, connect only the
single white audio output to the left input on your TV.
Connecting a VCR and TV with a
cable box
1 Connect the single (input) jack of the
Splitter to your incoming cable connection,
and connect the other two (output) jacks
(using coaxial cable) to IN on your cable
box and VHF/UHF on your TV.
2 Using a coaxial connector, connect OUT on
your cable box to IN on your VCR.
3 Using A/V connectors, connect AUDIO and
VIDEO OUT on your VCR to AUDIO and
VIDEO IN on your TV.
VIDEO IN
13
4
L
R
(MONO)
VIDEO
S VIDEO
OUT
AUDIO
L
R
Y
PB
PR
AUDIO
S-LINK
CONTROL S
AUX
TO
CONVERTER
VHF/UHF
AUDIO R AUDIO L VIDEO
S VIDEO
LINE
OUT
OUT
IN
Coaxial cable
(Rear of TV)
VMC-810S/820S (not supplied)
Cable
VCR
3
1
2
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
VIDEO IN
13
4
L
R
(MONO)
VIDEO
S VIDEO
OUT
AUDIO
L
R
Y
PB
PR
AUDIO
S-LINK
CONTROL S
AUX
TO
CONVERTER
VHF/UHF
AUDIO R AUDIO L VIDEO
S VIDEO
LINE
OUT
OUT
IN
OUT
IN
(Rear of TV)
VMC-810S/820S (not supplied)
Cable box
Splitter
(not supplied)
3
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
VCR
Cable
Coaxial cable
2
1
For optimum picture quality, use S VIDEO
instead of the yellow A/V cable. S VIDEO
does not provide sound, your audio
connectors must still be connected.
6
Connecting two VCRs
MONITOR OUT gives you the ability to use a
second VCR to record a program being played
by the primary VCR or to perform tape
editing and dubbing.
1 Connect the VCR intended for playback
using the connection instructions on page
4 of this manual.
2 Using A/V connectors, connect AUDIO
and VIDEO IN on your VCR intended for
recording to MONITOR AUDIO and
VIDEO OUT on your TV.
Notes
· If you will be connecting your A/V
receiver to external speakers, you do not
need to connect AUDIO OUT on your
A/V receiver to AUDIO IN on your TV.
· You cannot record signals from equipment
connected to the Y, PB, PR input.
Connecting and Installing the TV (continued)
OUT
MONITOR AUDIO
(VAR/FIX)
TV
VIDEO IN
13
4
IN
L
R
(MONO)
VIDEO
VIDEO
S VIDEO
OUT
AUDIO
L
R
(MONO)
AUDIO
L
R
Y
PB
PR
AUDIO
S-LINK
CONTROL S
LINE
OUT
OUT
IN
LINE
IN
OUT
IN
AUDIO R AUDIO L VIDEO
AUDIO R AUDIO L VIDEO
VCR (for playback)
VCR (for recording)
VMC-810S/820S (not supplied)
VMC-810S/820S (not supplied)
(Rear of TV)
1
2
AUDIO-R (red)
AUDIO-L (white)
VIDEO (yellow)
Do not change the input
signal while editing through
MONITOR OUT.
Remote Control
Keepthisflapunfoldedandusethispage
forreference.
Getting to know the buttons on
the remote control
Names of the buttons on the remote
control are presented in different colors to
represent the available functions.
Button color
Clear ................ Press to select the component
you want to control; e.g.
VTR (VCR)/DVD, DBS (Direct
Broadcast Satellite)/CABLE,
or TV
Green ............... Buttons relevant to power
operations, like turning the
TV, DBS (Direct Broadcast
Satellite)/CABLE, or
VTR (VCR)/DVD on or off
Label color
White ............... TV/VTR (VCR)/DVD/DBS
(Direct Broadcast Satellite)/
CABLE operation buttons
Yellow .............. PIP operation buttons
Blue .................. DBS (Direct Broadcast
Satellite) operation buttons
Green ............... SYSTEM OFF operation button
For a detailed explanation of most buttons, see
"Watching the TV" on page 15.
MENU
CH + /­
VOL + /­
JUMP
TV/DBS
(page 16)
RESET
(pages 21 and 22)
CODE SET
(pages 26-28)
SLEEP
TV/VTR (page 16)
DISPLAY
TV (POWER)
MUTING
TV (FUNCTION)
TV / VIDEO
PIP (pages 17-18)
ANT (pages 3 and 16)
0 - 9 buttons
ENTER
MTS/GUIDE (page 22)
Select buttons
(pages 13 and 19)
SYSTEM OFF
(page 16)
+
ENTER
DISPLAY
TV/VIDEO
1
2
3
4
5
6
7
8
0
9
CH
VOL
CODE SET
RESET
MENU
MTS
GUIDE
JUMP
SLEEP
CH
­
TV DBS
TV/VTR
POSITION
FREEZE
AUDIO
SWAP
TV/VIDEO
PIP
ANT
VTR/DVD
SYSTEM
OFF
VTR/DVD
POWER
DBS/CABLE
TV
MUTING
TV
DBS/CABLE
FUNCTION
TV
RM-Y167
