SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
Multimedia LCD Projector
May 2005 Digital Media Division
SM0554
CP-RX60W
(C12XM)
SERVICE MANUAL
Be sure to read this manual before servicing. To assure safety from fire, electric shock, injury, harmful
radiation and materials, various measures are provided in this Hitachi Multimedia LCD Projector. Be
sure to read cautionary items described in the manual to maintain safety before servicing.
Caution
1. When replac
ing the lamp, avoid burns to your fingers, as the lamp becomes very hot.
2. Never touch the lamp bulb with a finger or anything else. Never drop it or give it a shock. They may
cause bursting of the bulb.
3. This projector is provided with a high voltage circuit for the lamp. Do not touch the electric parts of
power unit (main), when turn
ing on the projector.
4. Do not touch the exhaust fan, during operation.
5. The LCD module assembly is likely to be damaged. If replacing the LCD LENS/PRISM assembly,
do not hold the FPC of the LCD module assembly.
6. Use the cables which are included with the projector or
as specified.
Service Warning
Warning
The technical information and parts shown in this
manual are not to be used for: the development,
design, production, storage or use of nuclear, chemical,
biological or missile weapons or other weapons of
mass destruction; or military purposes; or purposes that
endanger global safety and peace. Moreover, do not
sell, give, or export these items, or grant permission for
use to parties with such objectives. Forward all inquiries
to Hitachi Ltd.
1. Features ----------------------------------------------- 2
2. Specifications----------------------------------------- 2
3. Names of each part --------------------------------- 3
4. Adjustment -------------------------------------------- 5
5. Troubleshooting ------------------------------------ 11
6. Service points -------------------------------------- 16
7. Wiring diagram ------------------------------------- 31
8. Disassembly diagram----------------------------- 35
9. Replacement parts list---------------------------- 43
10.RS-232C communication ------------------------ 44
11. Block diagram -------------------------------------- 52
12.Connector connection diagram ---------------- 53
13.Basic circuit diagram------------------------------ 54
Contents


background image
2
CP-RX60(C12XM)
1. Features
· High Brightness
· Low Noise
· Compact Body
2. Specifications
Liquid clystal
panel
Drive system
TFT active matrix
Panel size
1.5cm (0.6 type)
Number of pixels
1024 (H) x 768 (V)
Lamp
165W UHB
RGB
signal
input
RGB IN
Video : Analog 0.7Vp-p(75 termination)
H/V. sync.: TTL level (positive/negative)
Composite sync.: TTL level
VIDEO
signal
input
VIDEO IN
1.0Vp-p(75 termination)
S-VIDEO IN
Y signal : 1.0±0.1Vp-p, (75 termination)
C signal : 0.286±0.1Vp-p(NTSC burst signal, 75 termination)
0.3±0.1Vp-p(PAL/SECAM burst signal, 75 termination)
AUDIO IN
200mVrms, 47k or more (max. 3.0Vp-p)
Speaker output
1W(mono)
Power supply
AC100~120V/2.7A,AC220~240V/1.5A
Power consumption
240W
Dimensions
285 (W) x 73 (H) x 202 (D) mm (Not including protruding parts)
Weight
2.2kg(5.5lbs)
Temperature range
Operation : 5~35°C
Storage : -20~60°C
Accessories
Remote control x 1
RGB cable x 1
Power cords x 3
Batteries x 2
Filter cover for bottom up use x 1
User's manuals x 1


background image
3
CP-RX60(C12XM)
3. Names of each part
S-VIDEO
VIDEO
AUDIO
RGB
CONTROL
K
Lens
Lens cover
Filter cover
(Air filter and intake vent
are inside.)
Elevator button
Elevator foot
Remote sensor
Focus ring
Vent
AC inlet
Power switch
Elevator button
S-VIDEO port
VIDEO port
CONTROL port
Projector
Lamp cover
(Lamp unit is inside.)
Elevator foot
Bottom side
Speaker
Front-Right side
Rear-Left side
Control buttons
Ports
(See below.)
Vent
Ports
AUDIO port
Restart switch
RGB port
Kensington lock slot
NOTE (*) About Restart switch: This Projector is controlled by an internal
microprocessor. Under certain exceptional circumstances, the projector may not
operate correctly and the microprocessor will need to be reset. In such a case,
please push the Restart switch by using a cocktail stick or similar and before
turning on again, make the projector cool down at least 10 minutes without
operating. Only push the Restart switch in these exceptional instances.
Part names


background image
4
CP-RX60(C12XM)
STANDBY/ON
INPUT
MENU
LAMP
TEMP
POWER
VIDEO
RGB
SEARCH
FREEZE
OFF
ON
MAGNIFY
ASPECT
AUTO
BLANK
MUTE
VOLUME
KEYSTONE
POSITION
ESC
ENTER
MENU
RESET
ZOOM +
-
LAMP indicator
TEMP indicator
POWER indicator
INPUT button
Cursor buttons
,,,
STANDBY/ON button
Controls
Remote control
SEARCH button
RGB button
VIDEO button
ASPECT button
MAGNIFY
ON button
OFF button
FREEZE button
POSITION button
ESC button
STANDBY/ON button
AUTO button
BLANK button
VOLUME button
MUTE button
KEYSTONE button
Zoom
+ button
- button
MENU button
Menu cursor buttons
,,,
ENTER button
RESET button


background image
5
CP-RX60(C12XM)
4. Adjustment
4-1 Before adjusting
4-1-1 Selection of adjustment
When any parts in the table 4-1 are changed, choose the proper adjusting items with the chart.
Table 4-1: Relation between the replaced part and adjustment
Replaced
part
Adjustment
Convergence
(Chap.4-2)
E-POS
(Chap.4-3)
Ghost
(Chap.4-4)
Flicker
(Chap.4-5)
NRSH
(Chap.4-6)
White
balance
(Chap.4-7)
Color
uniformity
(Chap.4-8)
Dichroic
optics unit
LCD/LENS
prism
assembly
PWB
assembly
Main
Lamp
unit
assembly
: means need for adjustment.
: means not need for djustment.
: means recommended.
4-1-2 Setting of condition before adjustment
1. Before starting adjustment, warm up projector
for about 10 minutes.
2. Set Zoom Wide to Max. And project an image
with more than 1m (40 inches) in diagonal size.
3. Normalizing the video adjustment
Press the [MENU] button to display the Easy
menu. If Advance menu comes up, move to the
Easy menu.
Select RESET in the Easy menu and press [ ]
or [ENTER] button to open the RESET menu
window. Choose EXECUTE with [ ] button.
Note that no signal input may not allow to reset
the adjustments.
4. Select PICTURE > GAMMA in the Advance
menu to set to DEFAULT1.
Note that PICTURE menu is not selectable with
no signal input displayed.
5. Select PICTURE > COLOR TEMP > CUSTOM
in the Advance menu, then press [ ] or [ENTER]
button to display the equalizing window. Set all
the values of OFFSET and GAIN in the window
to zero.
Caution: Before this performance, make a note
of your customer's adjustments, because the
data is overwritten.
6. Perform all adjustments from the FACTORY
MENU.
Perform the following operations to display the
FACTORY MENU.
< When you use the remote control... >
a. Press the [MENU] button of remote control to
display the Easy menu. (If the Advance menu
appears, move to the Easy menu from EASY
MENU.)
b. Select the [RESET] in the Easy menu, and
then press the [ ] or [ENTER] button.
c. Next, press the [RESET] button one time.
And hold the [RESET] button for 3 seconds
or more (the FACTORY MENU will appear).
< When you use the keypad... >
a. Press the [ ]/[ ]/[ ]/[ ] button of the projec-
tor to display the Easy menu. (If the Advance
menu appears, move to the Easy menu from
EASY MENU.)
b. Select the [RESET] in the Easy menu, and
then press the [ ] button.
c. Next, press the [
] button one time. And
repress and hold the [
] button together
with the [INPUT] button for 3 seconds or
more (the FACTORY MENU will appear).
